Three-Phase Industrial Induction Motor
Foot-mounted three-phase induction motor built on our in-house CNC-turned frames with Grade-A enameled copper windings. Routine and type tested before dispatch, and engineered to your voltage, RPM and duty-cycle requirements.
7.5 HP
Power
415V
Voltage
1440
RPM
IP55
Protection
Technical Specifications
Everything You Need to Know Before You Buy
Built for continuous industrial duty
This motor is manufactured end-to-end at our Ahmedabad facility — from CNC-turned frames and press-fit rotor assembly to in-house winding with Grade-A enameled copper. Every unit runs through our full battery of routine tests before it leaves the floor.
Available as a stock configuration or engineered to your exact voltage, frequency, mounting and duty-cycle needs for OEM production lines.
- CNC-machined frame & end-shields for tight tolerances
- Class F insulation with enameled copper windings
- Dynamically balanced rotor for low vibration & noise
- Routine tested: no-load, locked-rotor & insulation resistance
- Customizable RPM, mounting, terminal box position & shaft extension
HANSARAJ
RATING PLATE · IEC 60034
Model
HRJ-IM3-7.5
Output
7.5 HP / 5.5 kW
Phase
3-Phase
Voltage
415 V ± 6%
Frequency
50 Hz
Speed
1440 RPM
Full Load Current
10.4 A
Frame Size
132M
Mounting
B3 Foot Mount
Insulation Class
Class F
Protection
IP55
Duty
S1 Continuous
Efficiency Class
IE2
Weight
42 kg
Test Standard
IS 12615
SERIAL: HRJ-2026-000734
MADE IN AHMEDABAD, INDIA
MADE IN AHMEDABAD, INDIA
ⓘ Ratings shown for the standard configuration. Voltage, frequency, mounting and shaft dimensions can be customized for OEM orders — share your requirement for a tailored datasheet.
